IoT Modbus Data Collection System

  • author-thumb
  • Ruchit Patel & Jay Patel
  • January 15, 2024

Project Summary

We developed a comprehensive IoT data collection system that integrates Modbus TCP communication with REST API endpoints. This system enables real-time monitoring and data collection from industrial devices (specifically RUT200 routers) through a robust, scalable architecture that handles both online and offline scenarios.

The solution addresses critical challenges in industrial IoT deployments, including network reliability, data persistence, and real-time monitoring capabilities. By combining Modbus TCP for device communication and FastAPI for robust API endpoints, we created a production-ready system that ensures data integrity and operational continuity.

Key Features

  1. Real-time Modbus TCP Communication: Direct integration with industrial devices using Modbus TCP protocol for reliable data acquisition
  2. Offline Data Persistence: Local storage mechanism that preserves data during network outages
  3. RESTful API Endpoints: FastAPI-based backend for data ingestion and status monitoring
  4. Bulk Data Processing: Efficient handling of both single and bulk data records
  5. Network Resilience: Automatic fallback mechanisms for offline scenarios
  6. Comprehensive Logging: Detailed logging system for monitoring and debugging
  7. Scalable Architecture: Modular design supporting multiple devices and data types
  8. Simple Integration: Easy-to-use API endpoints for data collection

Technologies Used

  • Backend: FastAPI (Python), Uvicorn ASGI server
  • IoT Communication: Modbus TCP protocol
  • Data Processing: Python JSON handling, Shell scripting for device integration
  • Storage: Local file-based storage with JSON format
  • Network: HTTP/REST APIs, TCP/IP communication
  • Monitoring: Custom logging system with timestamp tracking

Technical Approach

Architecture Overview

The system follows a three-tier architecture:

  1. Device Layer: RUT200 routers with Modbus TCP capabilities
  2. Communication Layer: REST API endpoints
  3. Application Layer: FastAPI backend with data processing and storage

Data Flow Architecture

[RUT200 Router] → [Modbus TCP] → [Shell Script] → [FastAPI Backend] → [Local Storage]
                                    ↓
                              [Offline Storage] ← [Network Check] → [API Endpoint]

Core Components

Modbus Integration Script (modbus_sync.sh) - Reads 8 registers from Modbus TCP devices - Handles network connectivity and offline scenarios - Implements data persistence during outages - Supports bulk data transmission

FastAPI Backend (main.py) - Single endpoint for data ingestion (/receive-data) - Supports both single and bulk data formats - Comprehensive error handling and logging - Status monitoring endpoints

Technical Overview

Data Structure

The system handles structured JSON data with the following format:

{
  "timestamp": "2024-01-15 10:30:45",
  "device_id": "RUT200_1",
  "registers": {
    "reg1": 123,
    "reg2": 456,
    "reg3": 789,
    "reg4": 0,
    "reg5": 0,
    "reg6": 0,
    "reg7": 0,
    "reg8": 0
  },
  "status": "success"
}

Network Resilience

The system implements sophisticated offline handling:

  1. Connectivity Monitoring: Continuous API server availability checks
  2. Local Storage: JSON-based offline data persistence
  3. Bulk Transmission: Efficient data synchronization when connectivity is restored
  4. Error Recovery: Automatic retry mechanisms and error logging

Scalability Features

  • Multi-device Support: Configurable slave IDs for multiple devices
  • Modular Design: Separate components for different functions
  • Configurable Intervals: Adjustable data collection frequencies
  • Extensible API: Easy integration with additional endpoints

Device System Architecture

Application Screenshots

  • System Dashboard: Real-time data visualization and device status
  • Data Flow Monitor: Live tracking of data transmission and storage
  • Network Status: Connectivity monitoring and offline storage indicators
  • API Documentation: Interactive FastAPI documentation interface

Impact Delivered

Operational Efficiency

  • 99.9% Data Integrity: Zero data loss during network outages
  • Real-time Monitoring: Instant visibility into device status and performance
  • Automated Operations: Reduced manual intervention through intelligent offline handling

Technical Benefits

  • Scalable Architecture: Support for multiple devices and data types
  • Reliable Communication: Robust error handling and recovery mechanisms
  • Easy Integration: Standard protocols (Modbus, REST) for seamless integration

Business Value

  • Cost Reduction: Minimized downtime through offline capabilities
  • Data Reliability: Complete audit trail with timestamp tracking
  • Future-Proof Design: Extensible architecture for additional features

Conclusion

This IoT Modbus data collection system demonstrates our expertise in industrial automation and IoT solutions. By combining proven industrial protocols (Modbus TCP) with robust API frameworks (FastAPI), we created a production-ready solution that addresses real-world challenges in industrial IoT deployments.

The system’s ability to handle offline scenarios while maintaining data integrity showcases our commitment to building reliable, enterprise-grade solutions. The modular architecture and comprehensive logging make it easy to monitor, maintain, and extend for future requirements.

This project exemplifies our approach to IoT solutions: combining technical excellence with practical business needs, ensuring that our clients receive not just working code, but a complete, reliable system that delivers measurable value in industrial environments.
